| PartNumber | P101KDA-AK0 |
| Marca | Innolux |
| mărimea | 10.1 |
| Aplicație | Pad & Tablet |
| Rezoluţie | 1200×1920 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | |
| producător | Innolux |
| marimea ecranului | 10.1 inch |
| numărul de pixeli | 1200(RGB)×1920 (WUXGA) 225PPI |
| zona activa (mm) | 135.36 × 216.576 (H×V) |
| zona rama (mm) | - |
| luminanţă | 400 (Typ.)(cd/m²) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| vedere buna la | Symmetry |
| adâncimea culorii | 16.7M 70% NTSC |
| masa | 105g (Max.) |
| rată de reîmprospătare | 60Hz |
| numele modelului | P101KDA-AK0 |
| tipul de ecran | LCM , a-Si TFT-LCD |
| aranjament | RGB Vertical Stripe |
| contur (mm) | 142.96 × 235.887 × 3.3 (H×V×D) |
| tratament | Glare (Haze 0%), Hard coating |
| Raport de contrast | 1000 : 1 (Typ.) (TM) |
| modul de lucru | AAS, Normally Black, Transmissive |
| raspuns | 25 (Typ.)(Tr+Td) ms |
| lumina de fundal | WLED , 15K hours , No Driver |
| folosit pentru | Pad & Tablet |
| touch screen | Without |
| B101EW02 V0 | AUO | 10.1 | 1280×720 |
| B101UAN01.1 | AUO | 10.1 | 1920×1200 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| CLAA101WB03 | CPT | 10.1 | 1366×768 |
| G101STN01.2 | AUO | 10.1 | 1024×600 |
| HJ101IA-01I | Innolux | 10.1 | 1280×800 |
| HSD101PWW2-A00 | HannStar | 10.1 | 1280×800 |
| LTL101AL02-T01 | Samsung | 10.1 | 1280×800 |
| LTN101NT05-T01 | Samsung | 10.1 | 1024×600 |
| P101KDA-AP1 | Innolux | 10.1 | 1200×1920 |
