| PartNumber | NL8060BC26-17 |
| Marca | NLT |
| mărimea | 10.4 |
| Aplicație | IA |
| Rezoluţie | 800×600 |
| Compoziţie | LCM |
| Luminozitate | 280 |
| CR | 300:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | TTL |
| marca panoului | NEC |
| model de panou | NL8060BC26-17 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.4 inch |
| rezoluţie | 800(RGB)×600 , SVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 211.2×158.4 mm |
| contur | 243×185.1 mm |
| suprafaţă | Antireflection |
| luminozitatea | 280 cd/m² (Typ.) |
| Raport de contrast | 300:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193143% |
| timp de raspuns | 15/65 (Typ.)(Tr/Td) |
| unghi de vedere | 50/50/35/45 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 2 pcsCCFLWithout Driver |
| interfață de semnal | CMOS (1 ch, 6-bit), 41 pins |
| tensiune de intrare | 3.3/5.0V (Typ.)(VCC) |
| rohs: | |
| aplicarea | IA |
| NL8060AC26-04 | NLT | 10.4 | 800×600 |
| NL8060AC26-52D | NLT | 10.4 | 800×600 |
| NL8060BC21-03 | NLT | 8.4 | 800×600 |
| NL8060BC26-11 | NLT | 10.4 | 800×600 |
| NL8060BC26-13 | NLT | 10.4 | 800×600 |
| NL8060BC26-27 | NLT | 10.4 | 800×600 |
| NL8060BC26-30C | NLT | 10.4 | 800×600 |
| NL8060BC26-30D | NLT | 10.4 | 800×600 |
| NL8060BC31-27 | NLT | 12.1 | 800×600 |
| NL8060BC31-47D | NLT | 12.1 | 800×600 |
| 70WVW5A | SII | 7.0 | 800×480 |
| A050BTS30R0 | Aptus | 5.0 | 480×480 |
| DLC0570CDG-1 | Other | 5.7 | 320×240 |
| DLC1040ABG-2 | Other | 10.4 | 800×600 |
| LB121S03-TL04 | LG Display | 12.1 | 800×600 |
| LM-CA53-22NTK | SANYO | 9.4 | 640×480 |
| LM64P30 | SHARP | 9.4 | 640×480 |
| LTA084C274F | TOSHIBA | 8.4 | 800×600 |
| TM100SV-A01-01 | SANYO | 10.0 | 800×600 |
| UG-2896GDEAF11 | WiseChip | 1.3 | 128×96 |
