| PartNumber | A050BTS30R0 |
| Marca | Aptus |
| mărimea | 5.0 |
| Aplicație | IA |
| Rezoluţie | 480×480 |
| Compoziţie | LCM |
| Luminozitate | 1200 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | Aptus |
| model de panou | A050BTS30R0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 480(RGB)×480 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 87.3×87.3 mm |
| contur | 111.55×110 mm |
| suprafaţă | |
| luminozitatea | 1200 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 50/50/40/40 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDWithout Driver |
| interfață de semnal | TTL (1 ch, 6-bit), 60 pins |
| tensiune de intrare | 3.3/9.7/18/-6V (Typ.)(VDD1/VDD2/VGG/VEE) |
| aplicarea | IA |
