| PartNumber | NL328204AC19-01 |
| Marca | NLT |
| mărimea | 30.0 |
| Aplicație | Outdoor High Brightn |
| Rezoluţie | 3280×2048 |
| Compoziţie | LCM, a-Si TFT-LCD |
| Luminozitate | |
| CR | 1500:1 |
| Culori | 1.07B |
| Iluminare de fundal | WLED |
| Interfață | |
| producător | NLT |
| numele modelului | NL328204AC19-01 |
| marimea ecranului | 30.0 inch |
| tipul de ecran | LCM, a-Si TFT-LCD |
| numărul de pixeli | 3280(RGB)×2048 129PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 645.504 × 403.046 (H×V) |
| contur (mm) | 670 × 427 × 30.5 (H×V×D) |
| zona rama (mm) | - |
| tratament | Antiglare |
| luminanţă | 1000 cd/m² (Typ.) |
| Raport de contrast | 1500 : 1 (Typ.) (TM) |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥10) |
| raspuns | 25 (Typ.)(Tr+Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | SFT2, Normally Black, Transmissive |
| adâncimea culorii | 1.07B 72% NTSC |
| lumina de fundal | WLED , With LED Driver |
| masa | 5.50Kgs |
| folosit pentru | Outdoor High Brightness Medical Imaging |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C |
