| PartNumber | NL128102AC28-07 |
| Marca | NLT |
| mărimea | 18.1 |
| Aplicație | IA |
| Rezoluţie | 1280×1024 |
| Compoziţie | LCM |
| Luminozitate | 240 |
| CR | 300:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | NEC |
| model de panou | NL128102AC28-07 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 18.1 inch |
| rezoluţie | 1280(RGB)×1024 , SXGA |
| modul de afișare | A-SFT, Normally Black, Transmissive |
| Zonă activă | 359.04×287.232 mm |
| contur | 389×317.2×31.3 mm |
| suprafaţă | Hard coating (2H), Antireflection |
| luminozitatea | 240 cd/m² (Typ.) |
| Raport de contrast | 300:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193160% |
| timp de raspuns | 15/14 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 12 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (2 ch, 8-bit), 50 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | IA |
