N080ICE-GB0 Rev.C1

N080ICE-GB0 Rev.C1
N080ICE-GB0 Rev.C1
N080ICE-GB0 Rev.C1
N080ICE-GB0 Rev.C1 thumb N080ICE-GB0 Rev.C1 thumb N080ICE-GB0 Rev.C1 thumb
Marca
Innolux
mărimea
8.0
Aplicație
PAD
Rezoluţie
800×1280
Compoziţie
LCM
Luminozitate
400
CR
1000:1
Culori
16.7M
Iluminare de fundal
WLED
Interfață
MIPI
In Stock
3880
Specificații

PartNumber N080ICE-GB0 Rev.C1
MarcaInnolux
mărimea8.0
AplicațiePAD
Rezoluţie800×1280
CompoziţieLCM
Luminozitate400
CR1000:1
Culori16.7M
Iluminare de fundalWLED
InterfațăMIPI
marca panouluiINNOLUX
model de panouN080ICE-GB0 Rev.C1
tip panou a-Si TFT-LCD , LCM
dimensiunea panoului8.0 inch
rezoluţie800(RGB)×1280 , WXGA
modul de afișareAAS, Normally Black, Transmissive
Zonă activă107.64×172.224 mm
contur114.6×184.1×3.85 mm
suprafaţăGlare (Haze 0%), Hard coating
luminozitatea400 cd/m² (Typ.)
Raport de contrast1000:1 (Typ.)
culorile afișajului16.7M (8-bit), CIE193160%
timp de raspuns25 (Typ.)(Tr+Td)
unghi de vedere80/80/80/80 (Min.)(CR≥10)(L/R/U/D)
frecvență60Hz
tip lampa5 stringsWLEDWithout Driver
interfață de semnalMIPI (4 data lanes), 36 pins
tensiune de intrare1.8/3.3V (Typ.)(VDDI/VCI)
aplicareaPAD
