MT220WW01 V.6

MT220WW01 V.6
MT220WW01 V.6
MT220WW01 V.6 thumb MT220WW01 V.6 thumb
Marca
Innolux
mărimea
22.0
Aplicație
DMPC
Rezoluţie
1680×1050
Compoziţie
LCM
Luminozitate
250
CR
1000:1
Culori
16.7M
Iluminare de fundal
CCFL
Interfață
LVDS
In Stock
3862
Specificații

PartNumber MT220WW01 V.6
MarcaInnolux
mărimea22.0
AplicațieDMPC
Rezoluţie1680×1050
CompoziţieLCM
Luminozitate250
CR1000:1
Culori16.7M
Iluminare de fundalCCFL
InterfațăLVDS
marca panouluiINNOLUX
model de panouMT220WW01 V.6
tip panou a-Si TFT-LCD , LCM
dimensiunea panoului22.0 inch
rezoluţie1680(RGB)×1050 , WSXGA+
modul de afișareTN, Normally White, Transmissive
Zonă activă473.76×296.1 mm
contur493.7×320.1×16.7 mm
suprafaţăAntiglare (Haze 25%), Hard coating (3H)
luminozitatea250 cd/m² (Typ.)
Raport de contrast1000:1 (Typ.)
culorile afișajului16.7M (6-bit + Hi-FRC)
timp de raspuns1.5/3.5 (Typ.)(Tr/Td)
unghi de vedere85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
frecvență60Hz
tip lampa2 pcsCCFLWithout Driver
interfață de semnalLVDS (1 ch, 8-bit), 30 pins
tensiune de intrare5.0V (Typ.)
aplicareaDMPC
