| PartNumber | LTM236FL01 |
| Marca | Samsung |
| mărimea | 23.6 |
| Aplicație | DMPC |
| Rezoluţie | 3840×2160 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca panoului | SAMSUNG |
| model de panou | LTM236FL01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 23.6 inch |
| rezoluţie | 3840(RGB)×2160 , UHD |
| modul de afișare | PLS, Normally Black, Transmissive |
| Zonă activă | 521.28×293.22 mm |
| contur | 544.8×320.5×11 mm |
| suprafaţă | Antiglare (Haze 25%), Hard coating (3H) |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), sRGB100% |
| timp de raspuns | 14 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4 stringsWLEDWithout Driver |
| interfață de semnal | eDP (4 Lanes), 51 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
