| PartNumber | LTM030DH60 |
| Marca | TOSHIBA |
| mărimea | 3.0 |
| Aplicație | MPH |
| Rezoluţie | 240×427 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 800:1 |
| Culori | 262K |
| Iluminare de fundal | No B/L |
| Interfață | M-CMADS |
| marca panoului | TOSHIBA |
| model de panou | LTM030DH60 |
| tip panou | LTPS TFT-LCD , CELL |
| dimensiunea panoului | 3.0 inch |
| rezoluţie | 240(RGB)×427 |
| modul de afișare | TN, Normally White, Transflective |
| Zonă activă | 36.72×65.33 mm |
| contur | 40.52×72.63 mm |
| suprafaţă | |
| adâncimea sticlei | 0.10+0.20 mm |
| transmisivitatea | 5.4% (Typ.)(with Polarizer) |
| Raport de contrast | 800:1 (Typ.)(Transmissive)4:1 (Typ.)(Reflective) |
| culorile afișajului | 262K , CIE193164% |
| timp de raspuns | 45/45 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/70/70 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | M-CMADS + SPI, 22 pins |
| tensiune de intrare | 2.8/1.8V (Typ.)(VCC/VDDIO) |
| aplicarea | MPH |
