| PartNumber | LTL106HL01-001 |
| Marca | Samsung |
| mărimea | 10.6 |
| Aplicație | PAD |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | SAMSUNG |
| model de panou | LTL106HL01-001 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.6 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | PLS, Normally Black, Transmissive |
| Zonă activă | 234.72×132.03 mm |
| contur | 246.52×149.02×5.2 mm |
| suprafaţă | Glare (Haze 0%), Hard coating (2H) |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193150% |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 9S4PWLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (2 ch, 8-bit), 51 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
