| PartNumber | LQ150X1LW96 |
| Marca | SHARP |
| mărimea | 15.0 |
| Aplicație | IA |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM |
| Luminozitate | 500 |
| CR | 1500:1 |
| Culori | 16.2M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | SHARP |
| model de panou | LQ150X1LW96 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 15.0 inch |
| rezoluţie | 1024(RGB)×768 , XGA |
| modul de afișare | ASV, Normally Black, Transmissive |
| Zonă activă | 304.128×228.096 mm |
| contur | 326.5×253.5×10.1 mm |
| suprafaţă | Antiglare (Haze 25%), Hard coating (3H) |
| luminozitatea | 500 cd/m² (Typ.) |
| Raport de contrast | 1500:1 (Typ.) |
| culorile afișajului | 16.2M (6-bit + FRC), CIE193170% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 8-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
| LQ150X1LAM3 | SHARP | 15.0 | 1024×768 |
| LQ150X1LGC2 | SHARP | 15.0 | 1024×768 |
| LQ150X1LGN1 | SHARP | 15.0 | 1024×768 |
| LQ150X1LGN1A | SHARP | 15.0 | 1024×768 |
| LQ150X1LGN7 | SHARP | 15.0 | 1024×768 |
| LQ150X1LW12 | SHARP | 15.0 | 1024×768 |
| LQ150X1LW71U | SHARP | 15.0 | 1024×768 |
| LQ150X1LW72 | SHARP | 15.0 | 1024×768 |
| LQ150X1LW96 | SHARP | 15.0 | 1024×768 |
| LQ150X1LX95 | SHARP | 15.0 | 1024×768 |
| A150XN01 V0 | AUO | 15.0 | 1024×768 |
| AA104VC10 | Mitsubishi | 10.4 | 640×480 |
| EL320.256-FD7 HB | Lumineq | 4.8 | 320×256 |
| EL640.480-AG1 ET | Lumineq | 8.1 | 640×480 |
| LM100SS1T522 | SHARP | 10.0 | 800×600 |
| NL10276AC30-42C | NLT | 15.0 | 1024×768 |
| PD080SL2 | E Ink | 8.0 | 800×600 |
| TX16D18VM2CAB | KOE | 6.2 | 800×300 |
| UG-2832TLBGG01 | WiseChip | 1.0 | 128×32 |
| UG-2864HMBEG01 | WiseChip | 0.96 | 128×64 |
