| PartNumber | LQ150X1LGN7 |
| Marca | SHARP |
| mărimea | 15.0 |
| Aplicație | |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM |
| Luminozitate | 260 |
| CR | 350:1 |
| Culori | 16.2M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | SHARP |
| model de panou | LQ150X1LGN7 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 15.0 inch |
| rezoluţie | 1024(RGB)×768 , XGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 304.128×228.096 mm |
| contur | 326×252×11.5 mm |
| suprafaţă | Antiglare (Haze 28%), Hard coating (2H) |
| luminozitatea | 260 cd/m² (Typ.) |
| Raport de contrast | 350:1 (Typ.) |
| culorile afișajului | 16.2M (6-bit + FRC) |
| timp de raspuns | 5/20 (Typ.)(Tr/Td) |
| unghi de vedere | 60/60/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 2 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (1 ch, 8-bit), 20 pins |
| tensiune de intrare | 3.3V (Typ.) |
