| PartNumber | LQ070T5DG01 |
| Marca | SHARP |
| mărimea | 7.0 |
| Aplicație | CNS |
| Rezoluţie | 854×480 |
| Compoziţie | LCM |
| Luminozitate | 410 |
| CR | 60:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | TTL |
| marca panoului | SHARP |
| model de panou | LQ070T5DG01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 854(RGB)×480 , FWVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 155×87.12 mm |
| contur | 176.9×109.3 mm |
| suprafaţă | Antiglare |
| luminozitatea | 410 cd/m² (Typ.) |
| Raport de contrast | 60:1 (Min.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 30/50 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 31 pins |
| tensiune de intrare | 5/10/-10V (Typ.)(VSH/VGH/VGL) |
| aplicarea | CNS |
