| PartNumber | LB070WQ6-TD01 |
| Marca | LG Display |
| mărimea | 7.0 |
| Aplicație | CNS |
| Rezoluţie | 400×234 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | TTL |
| marca panoului | LG.Philips LCD |
| model de panou | LB070WQ6-TD01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 400(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 156.25×82.37 mm |
| contur | 167.5×93.2 mm |
| suprafaţă | |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | |
| unghi de vedere | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | CCFL |
| interfață de semnal | TTL (1 ch, 6-bit) |
| aplicarea | CNS |
| LB070WQ4-TM01 | LG Display | 7.0 | 480×234 |
| LB070WQ5-TD01 | LG Display | 7.0 | 480×240 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LB070WQ7-TD02 | LG Display | 7.0 | 480×234 |
| LB070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LB070WV3-SD01 | LG Display | 7.0 | 800×480 |
| LB070WV3-SD02 | LG Display | 7.0 | 800×480 |
| LB070WV4-TJ01 | LG Display | 7.0 | 800×480 |
| LB070WV6-TD08 | LG Display | 7.0 | 800×480 |
| LB070WV7-TD02 | LG Display | 7.0 | 800×480 |
| A070FW01 | AUO | 7.0 | 480×234 |
| AT080TN42 V.1 | Innolux | 8.0 | 800×600 |
| CLAA069LA0FCW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| G070Y2-L01 | Innolux | 7.0 | 800×480 |
| LB080WV4-A1 | LG Display | 8.0 | 800×480 |
| LQ065T5AR05 | SHARP | 6.5 | 400×234 |
| LQ065T9DR52U | SHARP | 6.5 | 400×240 |
| LQ070Y5DG20 | SHARP | 7.0 | 800×480 |
| LS800JT9001 | Innolux | 8.0 | 800×600 |
