| PartNumber | LB065WQ3-TD02 |
| Marca | LG Display |
| mărimea | 6.5 |
| Aplicație | VDP |
| Rezoluţie | 400×240 |
| Compoziţie | LCM |
| Luminozitate | 350 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | TTL |
| marca panoului | LG.Philips LCD |
| model de panou | LB065WQ3-TD02 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 6.5 inch |
| rezoluţie | 400(RGB)×240 , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 143.4×79.326 mm |
| contur | 155.3×91 mm |
| suprafaţă | |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 10/30 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | CMOS/TTL (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.)(VCC) |
| aplicarea | VDP |
