Innolux AT070TN07 V.D fișă de date, specificație, stocuri, aplicație www.looklcd-ro.com
LookLCD LookLCD


AT070TN07 V.D

AT070TN07 V.D
AT070TN07 V.D
AT070TN07 V.D thumb AT070TN07 V.D thumb
Marca
Innolux
mărimea
7.0
Aplicație
VDP
Rezoluţie
480×234
Compoziţie
LCM
Luminozitate
200
CR
300:1
Culori
Full color
Iluminare de fundal
WLED
Interfață
Analog
In Stock
4500
Specificații

PartNumber AT070TN07 V.D
MarcaInnolux
mărimea7.0
AplicațieVDP
Rezoluţie480×234
CompoziţieLCM
Luminozitate200
CR300:1
CuloriFull color
Iluminare de fundalWLED
InterfațăAnalog
marca panouluiINNOLUX
model de panouAT070TN07 V.D
tip panou a-Si TFT-LCD , LCM
dimensiunea panoului7.0 inch
rezoluţie480(RGB)×234
modul de afișareTN, Normally White, Transmissive
Zonă activă154.08×86.58 mm
contur164.9×100 mm
suprafaţăAntiglare
luminozitatea200 cd/m² (Typ.)
Raport de contrast300:1 (Typ.)
culorile afișajuluiFull color
timp de raspuns15/20 (Typ.)(Tr/Td)
unghi de vedere60/60/40/60 (Typ.)(CR≥10)(L/R/U/D)
tip lampa3S4PWLEDWithout Driver
interfață de semnalTFT Specific Analog RGB, 26 pins
tensiune de intrare(3.3/5.0)/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL)
rohs:
aplicareaVDP
