| PartNumber | LA090WH1-SL01 |
| Marca | LG Display |
| mărimea | 9.0 |
| Aplicație | Automotive Display |
| Rezoluţie | 1280×720 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca | LG Display |
| model | LA090WH1-SL01 |
| dimensiunea diagonalei | 9.0 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 1280(RGB)×720 [WXGA] 164PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 200.448(H)×106.056(V) mm |
| contur dim. | 213.2(H)×121.2(V) ×8.6(D) mm |
| zona rama | 203.148(H)×108.756(V) mm |
| tratament | Antiglare |
| luminanţă | 600 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Typ.) (TM) |
| direcția vizualizării | Symmetry |
| timp de raspuns | 17/13 (Max.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥10) |
| mod de operare | IPS, Normally Black, Transmissive |
| culoare suport | 16.7M 65% NTSC |
| sursă de lumină | WLED [6S3P] , 10K hours , W/O Driver |
| greutate | 219/224g (Typ./Max.) |
| proiectat pentru | Automotive Display |
| rata de cadre | 60Hz |
| panou tactil | Without |
| tipul de interfață | LVDS (1 ch, 8-bit) , 60 pins Connector |
| alimentare electrică | 3.3V (Typ.) |
| mediu inconjurator | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
