| PartNumber | KHB065HV1BD-M10 |
| Marca | Kyocera |
| mărimea | 6.5 |
| Aplicație | IA |
| Rezoluţie | 640×240 |
| Compoziţie | LCM |
| Luminozitate | |
| CR | 15:1 |
| Culori | Color |
| Iluminare de fundal | CCFL |
| Interfață | Parallel Data |
| marca panoului | Kyocera |
| model de panou | KHB065HV1BD-M10 |
| tip panou | CSTN-LCD , LCM |
| dimensiunea panoului | 6.5 inch |
| rezoluţie | 640(RGB)×240 , HVGA |
| modul de afișare | STN, Normally Black, Transflective |
| Zonă activă | 153.58×57.58 mm |
| suprafaţă | Glare (Haze 0%) |
| luminozitatea | |
| Raport de contrast | 15:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| culorile afișajului | Color |
| timp de raspuns | 200/150 (Typ.)(Tr/Td) |
| unghi de vedere | 50/50/30/40 (Typ.)(CR≥2)(L/R/U/D) |
| tip lampa | 1 pcsCCFL |
| interfață de semnal | Parallel Data (8-bit), 18 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
