| PartNumber | HSD070I651-D00-0299 |
| Marca | HannStar |
| mărimea | 7.0 |
| Aplicație | Digital Photo Frame |
| Rezoluţie | 480×234 |
| Compoziţie | CELL, a-Si TFT-LCD |
| Luminozitate | |
| CR | 500:1 |
| Culori | Full |
| Iluminare de fundal | No |
| Interfață | |
| producător | HannStar |
| numele modelului | HSD070I651-D00-0299 |
| marimea ecranului | 7.0 inch |
| tipul de ecran | CELL, a-Si TFT-LCD |
| numărul de pixeli | 480(RGB)×234 76PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 154.08 × 86.58 (H×V) |
| contur (mm) | 164.9 × 100 × 1.69 (H×V×D) |
| zona rama (mm) | - |
| tratament | Antiglare, Hard coating (3H) |
| luminanţă | 0 cd/m² |
| Raport de contrast | 500 : 1 (Typ.) (TM) |
| unghi de vedere | 60/60/40/60 (Typ.)(CR≥10) |
| raspuns | 5/20 (Typ.)(Tr/Td) ms |
| vedere buna la | 6 o'clock |
| modul de lucru | TN, Normally White, Transmissive |
| grosimea sticlei | 0.63+0.63 mm |
| transmisivitatea | 9.0% (Typ.)(with Polarizer) |
| adâncimea culorii | Full color |
| lumina de fundal | No B/L |
| masa | 55.3/58.3g (Typ./Max.) |
| folosit pentru | Digital Photo Frame Portable DVD Player |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
