| PartNumber | C070VW04 V6 |
| Marca | AUO |
| mărimea | 7.0 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | AUO |
| model de panou | C070VW04 V6 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | AMVA, Normally Black, Transmissive |
| Zonă activă | 152.4×91.44 mm |
| contur | 164.55×105.1×8.78 mm |
| suprafaţă | Glare (Haze 0%), Antireflection |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193155% |
| timp de raspuns | 10/25 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S3PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 50 pins |
| tensiune de intrare | 3.3/12.5/15.0/-9.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| aplicarea | CNS |
| C070VAN01.1 | AUO | 7.0 | 800×480 |
| C070VTN01.0 | AUO | 7.0 | 800×480 |
| C070VTN02.0 | AUO | 7.0 | 800×480 |
| C070VVN03.0 | AUO | 7.0 | 800×480 |
| C070VVN03.1 | AUO | 7.0 | 800×480 |
| C070VW02 V0 | AUO | 7.0 | 800×480 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| C070VW04 V0 | AUO | 7.0 | 800×480 |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| LA070WV1-TH01 | LG Display | 7.0 | 800×480 |
| LB035Q03-TD02 | LG Display | 3.5 | 320×240 |
| LB043WQ4-TD01 | LG Display | 4.3 | 480×272 |
| LB058WQ1-SD01 | LG Display | 5.8 | 400×240 |
| LB080WV4-A1 | LG Display | 8.0 | 800×480 |
| LQ065T9BR51U | SHARP | 6.5 | 400×240 |
| PA050DS7 | E Ink | 5.0 | 320×234 |
| PW065XS1 | E Ink | 6.5 | 400×234 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
