| PartNumber | GV101WXB-NZ1-DGP0 |
| Marca | BOE |
| mărimea | 10.1 |
| Aplicație | Industrial |
| Rezoluţie | 1280×800 |
| Compoziţie | CELL, a-Si TFT-LCD |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | No |
| Interfață | |
| producător | BOE |
| numele modelului | GV101WXB-NZ1-DGP0 |
| marimea ecranului | 10.1 inch |
| tipul de ecran | CELL, a-Si TFT-LCD |
| numărul de pixeli | 1280(RGB)×800 (WXGA) 149PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 216.96 × 135.6 (H×V) |
| contur (mm) | 221.96 × 144.43 × 1.06 (H×V×D) |
| zona rama (mm) | - |
| tratament | Without Polarizer, Hard coating |
| luminanţă | 0 cd/m² |
| Raport de contrast | 1000 : 1 (Typ.) (TM) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| raspuns | 35 (Typ.)(Tr+Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | ADS, Normally Black, Transmissive |
| adâncimea culorii | 16.7M 50% NTSC |
| lumina de fundal | No B/L , With LED Driver |
| masa | - |
| folosit pentru | Industrial |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| B101UAN07.2 | AUO | 10.1 | 1200×1920 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| BP101WX1-210 | BOE | 10.1 | 1280×800 |
| CLAA101WJ02 | CPT | 10.1 | 1366×768 |
| HE101NA-02C | Innolux | 10.1 | 1280×800 |
| HSD101PFW1-A01 | HannStar | 10.1 | 1024×576 |
| LP101WH4-SLAA | LG Display | 10.1 | 1366×768 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| N101L6-L0A | Innolux | 10.1 | 1024×600 |
| TT101WSQ-N10 | BOE | 10.1 | 1024×600 |
