| PartNumber | G070VAN01.1 |
| Marca | AUO |
| mărimea | 7.0 |
| Aplicație | Industrial |
| Rezoluţie | 800×480 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 1300:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | 7S2P |
| Interfață | LVDS |
| producător | AUO |
| marimea ecranului | 7.0 inch |
| numărul de pixeli | 800×480(RGB) (WVGA) 133PPI |
| zona activa (mm) | 152.4 × 91.44 (H×V) |
| zona rama (mm) | 154.2 × 93.24 (H×V) |
| luminanţă | 200 cd/m² (Typ.) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| vedere buna la | Symmetry |
| adâncimea culorii | 262K/16.7M 60% NTSC |
| masa | 160g (Typ.) |
| rată de reîmprospătare | 60Hz |
| tipul semnalului | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| alimentare cu tensiune | 3.3V (Typ.) |
| max. evaluări | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| numele modelului | G070VAN01.1 |
| tipul de ecran | LCM , a-Si TFT-LCD |
| aranjament | RGB Horizontal Stripe |
| contur (mm) | 166.6 × 107 × 10 (H×V×D) |
| tratament | Antiglare |
| Raport de contrast | 1300 : 1 (Typ.) (TM) |
| raspuns | 11/19 (Max.)(Tr/Td) ms |
| modul de lucru | AHVA, Normally Black, Transmissive |
| lumina de fundal | 7S2P WLED , 30K hours , No Driver |
| folosit pentru | Industrial |
| touch screen | Without |
