| PartNumber | C090EAN04.1 |
| Marca | AUO |
| mărimea | 9.0 |
| Aplicație | Outdoor High Brightn |
| Rezoluţie | 1280×720 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca | AUO |
| model | C090EAN04.1 |
| dimensiunea diagonalei | 9.0 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 1280(RGB)×720 [WXGA] 163PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 198.72(H)×111.78(V) mm |
| contur dim. | 212.2(H)×127.9(V) ×11(D) mm |
| zona rama | 202.02(H)×115.78(V) mm |
| tratament | Antiglare |
| luminanţă | 900 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) (TM) |
| direcția vizualizării | Symmetry |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| mod de operare | AHVA, Normally Black, Transmissive |
| culoare suport | 16.7M 72% NTSC |
| sursă de lumină | WLED [8S3P] , 10K hours , W/O Driver |
| greutate | TBD |
| proiectat pentru | Outdoor High Brightness Automotive Display |
| rata de cadre | 60Hz |
| panou tactil | Without |
| tipul de interfață | LVDS (1 ch, 8-bit) , 40 pins FPC |
| alimentare electrică | 3.3V (Typ.) |
| mediu inconjurator | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
