| PartNumber | B101XAN01.3 |
| Marca | AUO |
| mărimea | 10.1 |
| Aplicație | PAD |
| Rezoluţie | 1366×768 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 900:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | B101XAN01.3 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 10.1 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | AHVA, Normally Black, Transmissive |
| Zonă activă | 222.52×125.11 mm |
| contur | 230.62×135.81×0.805 mm |
| suprafaţă | Hard coating, Antireflection |
| adâncimea sticlei | 0.25+0.25 mm |
| Raport de contrast | 900:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193150% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | LVDS (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
| B101XAN01.3 | AUO | 10.1 | 1366×768 |
| B101XAN02.0 | AUO | 10.1 | 1366×768 |
| B101XTN01.1 | AUO | 10.1 | 1366×768 |
| BT101IW04 V.0 | Innolux | 10.1 | 1024×600 |
| HSD100IFW1-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW2-B01 | HannStar | 10.1 | 1024×600 |
| LTL101AL06-002 | Samsung | 10.1 | 1280×800 |
| LTN101NT07-W01 | Samsung | 10.1 | 1024×600 |
| M101NWT4 R3 | IVO | 10.1 | 1024×600 |
| YXD101301000-60 | SEBO | 10.1 | 1024×600 |
| B101EAN01.3 | AUO | 10.1 | 1280×800 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| BP080WX1-100 | BOE | 8.0 | 1280×800 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| HX104X01-212 | HYDIS | 10.4 | 1024×768 |
| LD101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LQ079L1SX02 | SHARP | 7.9 | 1536×2048 |
| Q101IRE-LA1 | Innolux | 10.1 | 1280×800 |
