AUO B101UAN01.7 HW0A fișă de date, specificație, stocuri, aplicație www.looklcd-ro.com
LookLCD LookLCD


B101UAN01.7 HW0A

B101UAN01.7 HW0A
B101UAN01.7 HW0A
B101UAN01.7 HW0A
B101UAN01.7 HW0A thumb B101UAN01.7 HW0A thumb B101UAN01.7 HW0A thumb
Marca
AUO
mărimea
10.1
Aplicație
PAD
Rezoluţie
1920×1200
Compoziţie
LCM
Luminozitate
400
CR
800:1
Culori
16.7M
Iluminare de fundal
WLED
Interfață
MIPI
In Stock
7648
Specificații

PartNumber B101UAN01.7 HW0A
MarcaAUO
mărimea10.1
AplicațiePAD
Rezoluţie1920×1200
CompoziţieLCM
Luminozitate400
CR800:1
Culori16.7M
Iluminare de fundalWLED
InterfațăMIPI
marca panouluiAUO
model de panouB101UAN01.7 HW0A
tip panou a-Si TFT-LCD , LCM
dimensiunea panoului10.1 inch
rezoluţie1920(RGB)×1200 , WUXGA
modul de afișareAHVA, Normally Black, Transmissive
Zonă activă216.81×135.5 mm
contur227.72×147.8×5.35 mm
suprafaţăGlare (Haze 0%)
luminozitatea400 cd/m² (Typ.)
Raport de contrast800:1 (Typ.)
culorile afișajului16.7M (8-bit), CIE193150%
timp de raspuns25 (Typ.)(Tr+Td)
unghi de vedere85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
frecvență60Hz
tip lampaWLEDEmbedded (LED Driver)
interfață de semnalMIPI (4 data lanes), 34 pins
tensiune de intrare3.3V (Typ.)
aplicareaPAD
Model de familie
B101UAN01.1 AUO 10.1 1920×1200
B101UAN01.7 HW0A AUO 10.1 1920×1200
B101UAN01.7 HW1A AUO 10.1 1920×1200
B101UAN01.7 HW2A AUO 10.1 1920×1200
B101UAN01.9 AUO 10.1 1920×1200
B101UAN01.C AUO 10.1 1920×1200
B101UAN01.E AUO 10.1 1920×1200
B101UAN02.1 AUO 10.1 1920×1200
B101UAN07.0 AUO 10.1 1200×1920
B101UAN07.2 AUO 10.1 1200×1920
