| PartNumber | AMS767KC04-1 |
| Marca | Samsung |
| mărimea | 7.7 |
| Aplicație | PAD |
| Rezoluţie | 1280×800 |
| Compoziţie | Assembly |
| Luminozitate | 250 |
| CR | 3400:1 |
| Culori | 16.7M |
| Iluminare de fundal | self |
| Interfață | MIPI |
| marca panoului | SAMSUNG |
| model de panou | AMS767KC04-1 |
| tip panou | AM-OLED , Assembly |
| dimensiunea panoului | 7.7 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| Zonă activă | 165.12×103.2 mm |
| contur | 197.7×128.4 mm |
| suprafaţă | Anti Fingerprint |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 3400 : 1 (Min.) |
| culorile afișajului | 16.7M (8-bit), CIE1931110% |
| unghi de vedere | 88/88/88/88 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | MIPI (4 data lanes), 44 pins |
| tensiune de intrare | 6.3/1.8/3.0/5.8V (VDCDC/VDD3/VCI/VLIN1) |
| aplicarea | PAD |
