| PartNumber | AMCB004 |
| Marca | Samsung |
| mărimea | 2.4 |
| Aplicație | MPH |
| Rezoluţie | 240×320 |
| Compoziţie | OLED |
| Luminozitate | 200 |
| CR | 30000:1 |
| Culori | 262K |
| Iluminare de fundal | self |
| Interfață | CPU |
| marca panoului | SAMSUNG SDI |
| model de panou | AMCB004 |
| tip panou | AM-OLED , OLED |
| dimensiunea panoului | 2.4 inch |
| rezoluţie | 240(RGB)×320 , QVGA |
| Zonă activă | 36.72×48.96 mm |
| contur | 42.32×58.42 mm |
| suprafaţă | Antiglare, Hard coating (2H) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 30000 : 1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE1931106% |
| unghi de vedere | 90/90/90/90 (Max.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | CPU, 31 pins |
| tensiune de intrare | 3.0/3.8V (Typ.)(VDD/Vbat) |
| aplicarea | MPH |
