| PartNumber | PD024OX4 |
| Marca | E Ink |
| mărimea | 2.4 |
| Aplicație | DSC |
| Rezoluţie | 480×234 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | Serial RGB |
| marca panoului | PVI |
| model de panou | PD024OX4 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 2.4 inch |
| rezoluţie | 480×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 48×35.685 mm |
| contur | 55.2×47.55 mm |
| suprafaţă | Antiglare |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K |
| timp de raspuns | 6/15 (Typ.)(Tr/Td) |
| unghi de vedere | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 3S1PWLEDWithout Driver |
| interfață de semnal | Serial RGB (8-bit) + SPI, 40 pins |
| tensiune de intrare | 3.3/3.3/15/-8V (Typ.)(VCC/PVDD/VGH/VGL) |
| aplicarea | DSC |
| 24QVW2H | SII | 2.4 | 240×320 |
| A024CN02 VJ | AUO | 2.4 | 480×234 |
| A024CN02 VL | AUO | 2.4 | 480×234 |
| A024CN03 V2 | AUO | 2.4 | 480×234 |
| FX020410DNSWBG01 | Data Image | 2.4 | 480×234 |
| LTM024DC9B | TOSHIBA | 2.4 | 240×320 |
| PD024OX4 | E Ink | 2.4 | 480×234 |
| TD024THEB2 | TPO | 2.4 | 480×240 |
| TD024THEB5 | TPO | 2.4 | 480×240 |
| TM024HBZ26 | Tianma | 2.4 | 240×320 |
| 990000006 | TPO | 3.0 | 320×240 |
| A027DN01 VQ | AUO | 2.7 | 320×240 |
| A027DTN01.2 | AUO | 2.7 | 320×240 |
| A027DTN01.3 | AUO | 2.7 | 320×240 |
| A030DW01 V1 | AUO | 3.0 | 320×240 |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| LS027T3DG01 | SHARP | 2.7 | 320×240 |
| PA025XSF | E Ink | 2.5 | 480×234 |
| TM027CDH12 | Tianma | 2.7 | 320×240 |
