| PartNumber | AM-800480R2TMQW-U0H |
| Marca | AMPIRE |
| mărimea | 7.0 |
| Aplicație | Industrial |
| Rezoluţie | 800×480 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 250:1 |
| Culori | 65K |
| Iluminare de fundal | WLED |
| Interfață | UART |
| producător | AMPIRE |
| numele modelului | AM-800480R2TMQW-U0H |
| marimea ecranului | 7.0 inch |
| tipul de ecran | LCM , a-Si TFT-LCD |
| numărul de pixeli | 800(RGB)×480 (WVGA) 133PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 152.4 × 91.44 (H×V) |
| contur (mm) | 178.5 × 110 × 20.4 (H×V×D) |
| zona rama (mm) | 155.3 × 94.3 (H×V) |
| tratament | - |
| luminanţă | 400 cd/m² (Typ.) |
| Raport de contrast | 250 : 1 (Typ.) (TM) |
| unghi de vedere | 70/70/60/60 (Typ.)(CR≥10) |
| raspuns | 50 (Typ.)(Tr+Td) ms |
| vedere buna la | - |
| modul de lucru | TN, Normally White, Transmissive |
| adâncimea culorii | 65K 48% NTSC |
| lumina de fundal | WLED , With LED Driver |
| masa | - |
| folosit pentru | Industrial |
| rată de reîmprospătare | - |
| touch screen | Without |
| tipul semnalului | UART , 8 pins Connector |
| alimentare cu tensiune | 4.6/26.0V (Min./Typ.) |
| max. evaluări | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
