| PartNumber | AM-800480LTMQW-WAH |
| Marca | AMPIRE |
| mărimea | 5.0 |
| Aplicație | Industrial |
| Rezoluţie | 800×480 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | CPU |
| marca | AMPIRE |
| model | AM-800480LTMQW-WAH |
| dimensiunea diagonalei | 5.0 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 800(RGB)×480 [WVGA] 188PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 108(H)×64.8(V) mm |
| contur dim. | 118.5(H)×77.1(V) ×6.37(D) mm |
| zona rama | 110.6(H)×67.4(V) mm |
| tratament | - |
| luminanţă | 470 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) (TM) |
| direcția vizualizării | - |
| timp de raspuns | 15/35 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/70/50 (Typ.)(CR≥10) |
| mod de operare | TN, Normally White, Transmissive |
| culoare suport | 262K 52% NTSC |
| sursă de lumină | WLED [3S6P] , With LED Driver |
| greutate | TBD |
| proiectat pentru | Industrial |
| rata de cadre | 60Hz |
| panou tactil | Without |
| tipul de interfață | CPU , 40 pins Connector |
| alimentare electrică | 3.3V (Typ.) |
| mediu inconjurator | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
