| PartNumber | AM-800480CTZQW-A5H |
| Marca | AMPIRE |
| mărimea | 7.0 |
| Aplicație | Industrial Outdoor H |
| Rezoluţie | 800×480 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 262K |
| Iluminare de fundal | 6S5P |
| Interfață | LVDS |
| producător | AMPIRE |
| numele modelului | AM-800480CTZQW-A5H |
| marimea ecranului | 7.0 inch |
| tipul de ecran | LCM , a-Si TFT-LCD |
| numărul de pixeli | 800(RGB)×480 (WVGA) 133PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 152.4 × 91.44 (H×V) |
| contur (mm) | 165 × 104.4 × 11.61 (H×V×D) |
| zona rama (mm) | 15.48 × 93.85 (H×V) |
| tratament | - |
| luminanţă | 1500 cd/m² (Typ.) |
| Raport de contrast | 1000 : 1 (Typ.) (TM) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| raspuns | 25 (Typ.)(Tr+Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | IPS, Normally Black, Transmissive |
| adâncimea culorii | 262K 58% NTSC |
| lumina de fundal | 6S5P WLED , 50K hours , With LED Driver |
| masa | - |
| folosit pentru | Industrial Outdoor High Brightness |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| tipul semnalului | LVDS (1 ch, 6-bit) , 20 pins Connector |
| alimentare cu tensiune | 12.0V (Typ.) |
| max. evaluări | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
