| PartNumber | AM-800480AZTMQW-50H |
| Marca | AMPIRE |
| mărimea | 5.0 |
| Aplicație | Industrial |
| Rezoluţie | 800×480 |
| Compoziţie | a-Si TFT-LCD , LCM |
| Luminozitate | |
| CR | 600:1 |
| Culori | 16.7M |
| Iluminare de fundal | 3S6P |
| Interfață | |
| marca panoului | AMPIRE |
| dimensiunea panoului | 5.0" |
| rezoluţie | 800(RGB)×480, WVGA, 188PPI |
| zona de afisare | 108(W)×64.8(H) mm |
| dimensiunea conturului | 119.7(W)×78(H) ×6.1(D) mm |
| luminozitatea | 1000 cd/m² (Typ.) |
| unghi de vedere | 75/75/70/60 (Typ.)(CR≥10) |
| cea mai bună vedere pe | - |
| culorile afișajului | 16.7M 47% NTSC |
| frecvență | 60Hz |
| greutate | - |
| model de panou | AM-800480AZTMQW-50H |
| tip panou | a-Si TFT-LCD , LCM |
| format de pixeli | RGB Vertical Stripe |
| deschiderea ramei | - |
| suprafaţă | Antiglare |
| Raport de contrast | 600:1 (Typ.) (TM) |
| modul de afișare | TN, Normally White, Transmissive |
| timp de raspuns | 2/6 (Typ.)(Tr/Td) |
| tip lampa | 3S6P WLED , 50K hours , Without Driver |
| touch screen | Without |
| aplicarea | Industrial |
