| PartNumber | AM-640480GFTNQW-T01H-L |
| Marca | AMPIRE |
| mărimea | 5.7 |
| Aplicație | IA |
| Rezoluţie | 640×480 |
| Compoziţie | LCM |
| Luminozitate | 350 |
| CR | 250:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | AMPIRE |
| model de panou | AM-640480GFTNQW-T01H-L |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.7 inch |
| rezoluţie | 640(RGB)×480 , VGA |
| modul de afișare | TN, Normally White, Transflective |
| Zonă activă | 115.2×86.4 mm |
| contur | 127×98.43×9.24 mm |
| suprafaţă | |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 250:1 (Typ.)(Transmissive) |
| culorile afișajului | 262K (6-bit), CIE193149% |
| timp de raspuns | 50 (Typ.)(Tr+Td) |
| unghi de vedere | 70/70/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | TTL (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
