| PartNumber | SX25S004 |
| Marca | KOE |
| mărimea | 10.0 |
| Aplicație | IA |
| Rezoluţie | 800×600 |
| Compoziţie | LCM |
| Luminozitate | 100 |
| CR | 50:1 |
| Culori | Color |
| Iluminare de fundal | CCFL |
| Interfață | Parallel Data |
| marca panoului | HITACHI |
| model de panou | SX25S004 |
| tip panou | CSTN-LCD , LCM |
| dimensiunea panoului | 10.0 inch |
| rezoluţie | 800(RGB)×600 , SVGA |
| modul de afișare | STN, Normally Black, Transmissive |
| Zonă activă | 202.8×152.1 mm |
| contur | 236×168×6.3 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 100 cd/m² (Typ.) |
| Raport de contrast | 50:1 (Typ.) |
| culorile afișajului | Color |
| timp de raspuns | 170/130 (Typ.)(Tr/Td) |
| unghi de vedere | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| frecvență | 120Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | Parallel Data (2ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
