| PartNumber | AM-1280800P4TZQW-T11H |
| Marca | AMPIRE |
| mărimea | 7.0 |
| Aplicație | Industrial |
| Rezoluţie | 1280×800 |
| Compoziţie | a-Si TFT-LCD , LCM |
| Luminozitate | |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | 6S4P |
| Interfață | |
| marca panoului | AMPIRE |
| dimensiunea panoului | 7.0" |
| rezoluţie | 1280(RGB)×800, WXGA, 217PPI |
| zona de afisare | 149.76(W)×93.6(H) mm |
| dimensiunea conturului | 162.3(W)×107.9(H) ×11.8(D) mm |
| luminozitatea | 850 cd/m² (Typ.) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| cea mai bună vedere pe | Symmetry |
| culorile afișajului | 16.7M 50% NTSC |
| frecvență | 60Hz |
| greutate | - |
| model de panou | AM-1280800P4TZQW-T11H |
| tip panou | a-Si TFT-LCD , LCM |
| format de pixeli | RGB Vertical Stripe |
| deschiderea ramei | 152.76(W)×96.6(H) mm |
| suprafaţă | - |
| Raport de contrast | 800:1 (Typ.) (TM) |
| modul de afișare | SFT, Normally Black, Transmissive |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| tip lampa | 6S4P WLED , 50K hours , With LED Driver |
| touch screen | PCAP |
| aplicarea | Industrial |
| 70WVW2T | SII | 7.0 | 800×480 |
| AA070MC11 | Mitsubishi | 7.0 | 800×480 |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-00H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| BP070WX1-100 | BOE | 7.0 | 1280×800 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| HSD070IDW1-A00 | HannStar | 7.0 | 800×480 |
| LTA070B052F | TOSHIBA | 7.0 | 800×480 |
| N070ICE-G02 Rev.C3 | Innolux | 7.0 | 800×1280 |
