| PartNumber | AM-1024600K7TMQW-T54H |
| Marca | AMPIRE |
| mărimea | 7.0 |
| Aplicație | Industrial |
| Rezoluţie | 1024×600 |
| Compoziţie | LCM, a-Si TFT-LCD |
| Luminozitate | |
| CR | 700:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | 8S3P |
| Interfață | |
| producător | AMPIRE |
| numele modelului | AM-1024600K7TMQW-T54H |
| marimea ecranului | 7.0 inch |
| tipul de ecran | LCM, a-Si TFT-LCD |
| numărul de pixeli | 1024(RGB)×600 (WSVGA) 169PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 153.6 × 90 (H×V) |
| contur (mm) | 165.5 × 104.44 × 10.77 (H×V×D) |
| luminanţă | 850 cd/m² (Typ.) |
| Raport de contrast | 700 : 1 (Typ.) (TM) |
| unghi de vedere | 75/75/70/75 (Typ.)(CR≥10) |
| raspuns | 20/20 (Typ.)(Tr/Td) ms |
| vedere buna la | 6 o'clock |
| modul de lucru | TN, Normally White, Transmissive |
| adâncimea culorii | 262K/16.7M |
| lumina de fundal | 8S3P WLED , 50K hours , With LED Driver |
| masa | TBD |
| folosit pentru | Industrial |
| rată de reîmprospătare | 60Hz |
| touch screen | PCAP |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
