| PartNumber | A101AIE40L0 |
| Marca | Aptus |
| mărimea | 10.1 |
| Aplicație | IA |
| Rezoluţie | 1280×720 |
| Compoziţie | LCM |
| Luminozitate | 500 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | Aptus |
| model de panou | A101AIE40L0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.1 inch |
| rezoluţie | 1280(RGB)×720 , WXGA |
| modul de afișare | AHVA, Normally Black, Transmissive |
| Zonă activă | 223.68×125.82 mm |
| contur | 238.6×148 mm |
| suprafaţă | |
| luminozitatea | 500 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC) |
| timp de raspuns | 40 (Max.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 9S3PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3/3.3V (Typ.)(VDD/AVDD) |
| aplicarea | IA |
