| PartNumber | A085FW01 V5 |
| Marca | AUO |
| mărimea | 8.5 |
| Aplicație | DPF |
| Rezoluţie | 480×234 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 300:1 |
| Culori | |
| Iluminare de fundal | CCFL |
| Interfață | Analog |
| marca panoului | AUO |
| model de panou | A085FW01 V5 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 8.5 inch |
| rezoluţie | 480(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 187.2×105.3 mm |
| contur | 199×119 mm |
| suprafaţă | Antiglare |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 300:1 (Typ.) |
| culorile afișajului | |
| timp de raspuns | 12/18 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | TFT Specific Analog RGB, 26 pins |
| tensiune de intrare | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplicarea | DPF |
| A085FW01 V5 | AUO | 8.5 | 480×234 |
| G085VW01 V0 | AUO | 8.5 | 800×480 |
| G085VW01 V2 | AUO | 8.5 | 800×480 |
| G085VW01 V3 | AUO | 8.5 | 800×480 |
| KMT085WV | Samsung | 8.5 | 800×480 |
| LM085YB1T01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG18 | SHARP | 8.5 | 800×480 |
| LQ085Y3DW01 | SHARP | 8.5 | 800×480 |
| A080SN01 V5 | AUO | 8.0 | 800×600 |
| A104SN03 V0 | AUO | 10.4 | 800×600 |
| A104SN03 V1 | AUO | 10.4 | 800×600 |
| AT070TN90 V.1 | Innolux | 7.0 | 800×480 |
| EJ080NA-05A | Innolux | 8.0 | 800×600 |
| HSD070IDW1-A30 | HannStar | 7.0 | 800×480 |
| HSD101PFW4-B01 | HannStar | 10.1 | 1024×600 |
| LQ070Y3DG01 | SHARP | 7.0 | 800×480 |
| LW700AT9309 | Innolux | 7.0 | 800×480 |
| PM070WM3 | E Ink | 7.0 | 800×480 |
