| PartNumber | A104SN03 V0 |
| Marca | AUO |
| mărimea | 10.4 |
| Aplicație | DPF |
| Rezoluţie | 800×600 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 500:1 |
| Culori | 262K/16.2M |
| Iluminare de fundal | CCFL |
| Interfață | TTL |
| marca panoului | AUO |
| model de panou | A104SN03 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.4 inch |
| rezoluţie | 800(RGB)×600 , SVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 211.2×158.4 mm |
| contur | 228.4×175.4×6.5 mm |
| suprafaţă | Antiglare |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K/16.2M (6-bit / 6-bit + Dithering), CIE193150% |
| timp de raspuns | 12/18 (Typ.)(Tr/Td) |
| unghi de vedere | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | TTL (1 ch, 6/8-bit) + SPI, 60 pins |
| tensiune de intrare | 3.3/11/15/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplicarea | DPF |
| A104SN01 V0 | AUO | 10.4 | 800×600 |
| A104SN03 V0 | AUO | 10.4 | 800×600 |
| A104SN03 V1 | AUO | 10.4 | 800×600 |
| AA104SH02 | Mitsubishi | 10.4 | 800×600 |
| LM64C35P | SHARP | 10.4 | 640×480 |
| LQ104S1DG61 | SHARP | 10.4 | 800×600 |
| LQ104S1LG61 | SHARP | 10.4 | 800×600 |
| LQ10W03A | SHARP | 10.4 | 1024×600 |
| LTD104EA5W | TOSHIBA | 10.4 | 1024×768 |
| PD104VT1 | E Ink | 10.4 | 640×480 |
| A080SN01 V5 | AUO | 8.0 | 800×600 |
| A101VW01 V1 | AUO | 10.1 | 800×480 |
| A104SN01 V0 | AUO | 10.4 | 800×600 |
| A104SN03 V1 | AUO | 10.4 | 800×600 |
| AT102TN03 V.9 | Innolux | 10.2 | 800×480 |
| CLAA070MA21BW | CPT | 7.0 | 800×600 |
| HJ080IA-01F | Innolux | 8.0 | 1024×768 |
| HSD101PFW2-B00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW2-B01 | HannStar | 10.1 | 1024×600 |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
