| PartNumber | A056VN01 V0 |
| Marca | AUO |
| mărimea | 5.6 |
| Aplicație | |
| Rezoluţie | 640×480 |
| Compoziţie | LCM |
| Luminozitate | 350 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | AUO |
| model de panou | A056VN01 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.6 inch |
| rezoluţie | 640(RGB)×480 , VGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 112.8×84.6 mm |
| contur | 126.5×100 mm |
| suprafaţă | Antiglare |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 15/25 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 3S7PWLEDEmbedded (LED Driver) |
| interfață de semnal | Parallel RGB (1 ch, 6-bit) + SPI, 40 pins |
| tensiune de intrare | 3.3V (Typ.)(VDD) |
| rohs: |
