| PartNumber | A035VL01 V3 |
| Marca | AUO |
| mărimea | 3.5 |
| Aplicație | DVC |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 315 |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | AUO |
| model de panou | A035VL01 V3 |
| tip panou | LTPS TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 75.6×45.36 mm |
| contur | 86.1×51.66 mm |
| suprafaţă | Glare (Haze 0%) |
| luminozitatea | 315 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 15/30 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit) + SPI, 70 pins |
| tensiune de intrare | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| aplicarea | DVC |
