| PartNumber | TX31D200VM0BAA |
| Marca | KOE |
| mărimea | 12.3 |
| Aplicație | IA |
| Rezoluţie | 1280×480 |
| Compoziţie | LCM |
| Luminozitate | 1000 |
| CR | 1000:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | KOE |
| model de panou | TX31D200VM0BAA |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 12.3 inch |
| rezoluţie | 1280(RGB)×480 , DVGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 291.84×109.44 mm |
| contur | 320×130×12.6 mm |
| suprafaţă | Antiglare |
| luminozitatea | 1000 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193170% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6-bit), 20 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
