| PartNumber | TM123XDHP90 |
| Marca | TIANMA |
| mărimea | 12.3 |
| Aplicație | Industrial Outdoor H |
| Rezoluţie | 1920×720 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | 10S4P |
| Interfață | LVDS |
| marca panoului | TIANMA |
| model de panou | TM123XDHP90 |
| dimensiunea panoului | 12.3" |
| tip panou | a-Si TFT-LCD, LCM |
| rezoluţie | 1920(RGB)×720, 166PPI |
| format de pixeli | RGB Vertical Stripe |
| zona de afisare | 292.32(W)×109.62(H) mm |
| deschiderea ramei | - |
| dimensiunea conturului | 311(W)×130(H) ×15.7(D) mm |
| suprafaţă | Antiglare (Haze 28%) |
| luminozitatea | 1000 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) (TM) |
| unghi de vedere | - |
| modul de afișare | SFT, Normally Black, Transmissive |
| cea mai bună vedere pe | Symmetry |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| culorile afișajului | 16.7M 98% sRGB |
| tip lampa | 10S4P WLED , 10K hours , Without Driver |
| frecvență | 60Hz |
| touch screen | Without |
| greutatea panoului | 490g (Typ.) |
| aplicarea | Industrial Outdoor High Brightness Automotive Display |
| interfață de semnal | LVDS (2 ch, 8-bit) , 50 pins FPC |
| tensiune de intrare | 3.3V (Typ.) |
| mediu inconjurator | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
