| PartNumber | TM123XDHP01 |
| Marca | TIANMA |
| mărimea | 12.3 |
| Aplicație | Industrial Automotiv |
| Rezoluţie | 1920×720 |
| Compoziţie | a-Si TFT-LCD , LCM |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | |
| marca | TIANMA |
| dimensiunea diagonalei | 12.3 inch |
| format de pixeli | 1920(RGB)×720 166PPI |
| Zonă activă | 292.32(H)×109.62(V) mm |
| luminanţă | - |
| direcția vizualizării | Symmetry |
| unghi de vedere | - |
| culoare suport | 16.7M sRGB |
| greutate | - |
| rata de cadre | 60Hz |
| mediu inconjurator | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
| model | TM123XDHP01 |
| tip | a-Si TFT-LCD , LCM |
| configurație | RGB Vertical Stripe |
| contur dim. | - |
| Raport de contrast | 1000:1 (Typ.) (TM) |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| mod de operare | SFT, Normally Black, Transmissive |
| sursă de lumină | WLED |
| proiectat pentru | Industrial Automotive Display |
| panou tactil | Without |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
