| PartNumber | TM080TDHG01-42 |
| Marca | TIANMA |
| mărimea | 8.0 |
| Aplicație | Industrial |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | 3S9P |
| Interfață | |
| producător | TIANMA |
| marimea ecranului | 8.0 inch |
| numărul de pixeli | 1024(RGB)×768 (XGA) 160PPI |
| zona activa (mm) | 162.048 × 121.536 (H×V) |
| zona rama (mm) | 164.65 × 124.14 (H×V) |
| luminanţă | 400 (Typ.)(cd/m²) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| vedere buna la | 12 o'clock |
| adâncimea culorii | 262K/16.7M 50% NTSC |
| masa | 189g |
| rată de reîmprospătare | 60Hz |
| numele modelului | TM080TDHG01-42 |
| tipul de ecran | LCM , a-Si TFT-LCD |
| aranjament | RGB Vertical Stripe |
| contur (mm) | 183 × 141 × 3.7 (H×V×D) |
| tratament | Clear |
| Raport de contrast | 1000 : 1 (Typ.) (TM) |
| modul de lucru | TN, Normally White, Transmissive |
| raspuns | 20 (Typ.)(Tr+Td) ms |
| lumina de fundal | 3S9P WLED , 30K hours , No Driver |
| folosit pentru | Industrial |
| touch screen | Without |
| CLAA080LG02AW | CPT | 8.0 | 800×480 |
| HSD080IDW1-A00 | HannStar | 8.0 | 800×480 |
| L5F30614T23 | SANYO | 8.0 | 800×480 |
| L5F30614T64 | SANYO | 8.0 | 800×480 |
| LM64C219 | SHARP | 8.0 | 640×480 |
| LQ080Y5DG03 | SHARP | 8.0 | 800×480 |
| N080ICE-GB0 Rev.A0 | Innolux | 8.0 | 800×1280 |
| N080XCG-L21 | Innolux | 8.0 | 1024×768 |
| P080KDZ-3Z1 | Innolux | 8.0 | 1200×1920 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
