| PartNumber | TM070RDH10-00 |
| Marca | TIANMA |
| mărimea | 7.0 |
| Aplicație | Industrial Digital P |
| Rezoluţie | 800×480 |
| Compoziţie | a-Si TFT-LCD , LCM |
| Luminozitate | |
| CR | 500:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | WLED |
| Interfață | |
| marca | TIANMA |
| dimensiunea diagonalei | 7.0 inch |
| format de pixeli | 800(RGB)×480 [WVGA] 134PPI |
| Zonă activă | 154.08(H)×85.92(V) mm |
| zona rama | 157.08(H)×89.39(V) mm |
| luminanţă | 450 cd/m² (Typ.) |
| direcția vizualizării | 12 o'clock |
| unghi de vedere | 70/70/50/70 (Typ.)(CR≥10) |
| culoare suport | 262K/16.7M 50% NTSC |
| greutate | TBD |
| rata de cadre | 60Hz |
| model | TM070RDH10-00 1 Compatible |
| tip | a-Si TFT-LCD , LCM |
| configurație | RGB Vertical Stripe |
| contur dim. | 164.9(H)×100(V) ×6(D) mm |
| tratament | Antiglare |
| Raport de contrast | 500:1 (Typ.) (TM) |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| mod de operare | TN, Normally White, Transmissive |
| sursă de lumină | WLED [3S8P] , 20K hours , W/O Driver |
| proiectat pentru | Industrial Digital Photo Frame Portable DVD Player |
| panou tactil | Without |
| LB070WV6-TD06 | LG Display | 7.0 | 800×480 |
| PM070WT2 | E Ink | 7.0 | 800×480 |
| PW070NS1W2 | E Ink | 7.0 | 480×320 |
| Q070LRE-LB1 | Innolux | 7.0 | 1024×600 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TX18D41VM0EAA | KOE | 7.0 | 1024×600 |
