| PartNumber | T230XW01 V1 |
| Marca | AUO |
| mărimea | 23.0 |
| Aplicație | LCTV |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 700:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | T230XW01 V1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 23.0 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 508.152×285.696 mm |
| contur | 546×318.3 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 700:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193172% |
| timp de raspuns | 7/1 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 8 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (1 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | LCTV |
| LC230W01-A2 | LG Display | 23.0 | 1280×768 |
| LM230WF2-SLA2 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLQ1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLC1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLG1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLH1 | LG Display | 23.0 | 1920×1080 |
| LTA230AN01 | Samsung | 23.0 | 1366×768 |
| NL12876AC39-01 | NLT | 23.0 | 1280×768 |
| T230XW01 V1 | AUO | 23.0 | 1366×768 |
| T230XW01 V2 | AUO | 23.0 | 1366×768 |
| HV320WXC-100 | BOE | 31.5 | 1366×768 |
| LC550WUD-SBM4 | LG Display | 55 | 1920×1080 |
| LTA216AT01 | Samsung | 21.6 | 1366×768 |
| LTA230A172F | TOSHIBA | 23.0 | 1280×768 |
| LTA320HA04 | Samsung | 31.5 | 1920×1080 |
| LTA750FJ01 | Samsung | 75 | 3840×2160 |
| LTF320AP06 | Samsung | 31.5 | 1366×768 |
| LTF550HF04-A05 | Samsung | 55 | 1920×1080 |
| V290BJ1-L01 | Innolux | 29.0 | 1366×768 |
| V420HJ1-LE6 | Innolux | 42 | 1920×1080 |
