| PartNumber | LM230WF5-TLG1 |
| Marca | LG Display |
| mărimea | 23.0 |
| Aplicație | DMPC |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | LG Display |
| model de panou | LM230WF5-TLG1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 23.0 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 509.184×286.416 mm |
| contur | 533.2×312×10.7 mm |
| suprafaţă | Glare (Haze 0%), Hard coating (2H) |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193172% |
| timp de raspuns | 1.3/3.7 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 2 stringsWLEDWithout Driver |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
| LM230WF2-SLA1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLB2 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLD1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLL1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SSA1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLA3 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLD5 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLG1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TRA1 | LG Display | 23.0 | 1920×1080 |
| LM230WF8-TLA2 | LG Display | 23.0 | 1920×1080 |
| LM240WU2-SLB1 | LG Display | 24.0 | 1920×1200 |
| LTM150XS-T01 | Samsung | 15.0 | 1024×768 |
| LTM190E1-L03 | Samsung | 19.0 | 1280×1024 |
| LTM270RL01 | Samsung | 27.0 | 5120×2880 |
| M190EN03 V2 | AUO | 19.0 | 1280×1024 |
| M215H1-L03 | Innolux | 21.5 | 1920×1080 |
| M215HJK-L3B | Innolux | 21.5 | 1920×1080 |
| M220Z1-L09 | Innolux | 22.0 | 1680×1050 |
| M270HGE-L30 | Innolux | 27.0 | 1920×1080 |
| TMS150XG1-10TB Rev.E | Tianma | 15.0 | 1024×768 |
