| PartNumber | ST5461D01-1 |
| Marca | CSOT |
| mărimea | 55 |
| Aplicație | LCTV |
| Rezoluţie | 3840×2160 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 4000:1 |
| Culori | 1.07B |
| Iluminare de fundal | No B/L |
| Interfață | V-by-One |
| marca panoului | CSOT |
| model de panou | ST5461D01-1 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 55 inch |
| rezoluţie | 3840(RGB)×2160 , UHD |
| modul de afișare | HVA, Normally Black, Transmissive |
| Zonă activă | 1209.6×680.4 mm |
| contur | 1221.9×692.65 mm |
| suprafaţă | Antiglare (Haze 1.5%), Hard coating (3H) |
| adâncimea sticlei | 0.70+0.70 mm |
| transmisivitatea | 3.85% (Typ.)(with Polarizer) |
| Raport de contrast | 4000:1 (Typ.) |
| culorile afișajului | 1.07B (8-bit + Hi-FRC), CIE193172% |
| timp de raspuns | 6.5 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 120Hz |
| interfață de semnal | V-by-One 8 lane, 51 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | LCTV |
