| PartNumber | ST5461B05-1 |
| Marca | CSOT |
| mărimea | 55 |
| Aplicație | LCTV |
| Rezoluţie | 1920×1080 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 4000:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | LVDS |
| marca panoului | CSOT |
| model de panou | ST5461B05-1 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 55 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | HVA, Normally Black, Transmissive |
| Zonă activă | 1209.6×680.4 mm |
| contur | 1223.6×697.1 mm |
| suprafaţă | Antiglare (Haze 2%), Hard coating (3H) |
| adâncimea sticlei | 0.50+0.50 mm |
| transmisivitatea | 7.0% (Typ.)(with Polarizer) |
| Raport de contrast | 4000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193168% |
| timp de raspuns | 6.5 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 120Hz (60Hz Input) |
| interfață de semnal | LVDS (2 ch, 8-bit), 51 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | LCTV |
